Orange light-emitting PPV copolymer

产品说明

应用

Features:

• Soluble orange light-emitting PPV copolymer.
• Excellent reproducibility.
• Broad emission spectrum.
• High efficiency.
• Very low operation voltage.
• Very long DC and AC lifetime.
• High temperature stability (>100 ℃).

Typical performance measured in standard device stack (ITO/PEDOT:PSS 20 nm/PDO-123 80 nm/Ba 6 nm/Ag 150 nm):

• Max. efficiency: 5.0 Cd/A.
• V_on: 2.0 V.
• V at 100 cd/m²: 2.6 V.
• V at 1000 cd/m²: 3.3 V.
• Max. power eff.: 5.5 lm/W.
• External quantum eff.: 3.5%.
• CIE1931 at 100 cd/m²: (0.60, 0.40).
• DC lifetime at 100 cd/m² at RT: >>25000.

包装

1 g in poly bottle

制备说明

• 5 g/L in toluene for spin-coating.
• Special formulation needed for Inkjet.
• Preparation of device should be in N₂ atmosphere.

法律信息

Product of EMD Performance Materials Corp., an Affiliate of Merck KGaA, Darmstadt, Germany
Livilux is a trademark of Merck KGaA, Darmstadt, Germany

基本信息

NACRES

NA.23

产品性质

分子量	average Mn 340,000 average Mw 1,750,000
质量水平	100

安全信息

储存分类代码	13 - Non Combustible Solids
WGK	WGK 3
闪点(F)	Not applicable
闪点(C)	Not applicable
