产品说明
应用
This product is a conductive ink based on single-crystal silver nanoparticles in a mixture of propylene glycol monomethyl ether - diethylene glycol monomethyl ether solvents (PM-DGME), has been designed for Aerosol digital printing systems and low temperature sintering applications. The ink offers a unique combination of properties, including high silver loading, low viscosity, storage at ambient conditions, long shelf life, reliable jetting and good printability. Printed patterns, sinterable at low temperatures, provide low electrical resistivity, good adhesion to a wide range of substrates and durability to humid and aqueous environments.
This product can be stored at room temperature.
- Compatible printheads
- Product fit for:
Printed Electronics: FPD, RFID, PCB
Aerosol Jet can print conformal interconnects on 3D surfaces eliminating the need for wire bonding - for example printing electrical connections on 3D stacked die or for LED chip fabrication. Components can also be printed onto 3 dimensional surfaces eliminating the need for a separate substrate thereby reducing the size, thickness and weight of the end product. For example, Aerosol Jet is used to print antennas and sensors that conform to the shape of the underlying substrate such as a cell phone case. The Aerosol Jet process also supports printing on a wide variety of substrates including plastics, ceramics and metallic structures.
制备说明
Mix well before use.
Electrical Properties
Sintering conditions (on glass) :
UV followed by thermal (UV 9 W/cm2, 2 min (+), Thermal: 130℃/60 min)
Resistivity after sintering conditions mentioned above : ≤10 μΩ·cm (≤6 bulk)
Adhesion to (tested) :
Kapton, PC, PC/ABS, PA, glass
Reliability :
Adhesion survived below testing conditions (on glass):
soaking in NaCl 1M for 2 h
soaking in NaCl 1M for 2 h and in DI water for 20 h
法律信息
Lumisizer is a trademark of LUM GmbH
基本信息
| 线性分子式 | Ag |
产品性质
| 组成 | Propylene glycol monomethyl ether - diethylene glycol monomethyl ether solvents (PM-DGME) (solvent) Silver content, 60 wt. % |
| 粒径分布 | 100 nm (D90 by Lumisizer™) 75 nm (D50) |
| 表面张力 | , 23dyn/cm (Pendant Drop) |
| 粘度 | 26 cP (Brookfield, Cone Spindle 40, 25 ℃Brookfield, Cone Spindle 40, 25 ℃) |
| 密度 | 2.14 g/mL |
| 储存温度 | 15-25℃ |
安全信息
| 象形图 |     |
| 警示用语： | Warning |
| 危险声明 | H226 - H290 - H315 - H319 - H351 - H361d - H410 |
| 预防措施声明 | P202 - P210 - P273 - P303 + P361 + P353 - P305 + P351 + P338 - P308 + P313 |
| 危险分类 | Aquatic Acute 1 - Aquatic Chronic 1 - Carc. 2 - Eye Irrit. 2 - Flam. Liq. 3 - Met. Corr. 1 - Repr. 2 - Skin Irrit. 2 |
| 储存分类代码 | 3 - Flammable liquids |
| WGK | WGK 3 |
| 闪点(F) | 85.1 °F |
| 闪点(C) | 29.5 ℃ |
