产品说明
一般描述
The Büchi micro distillation system is ideal for drying, distilling, and the sublimation of small-volume samples from ambient temperatures up to 300℃.
Fast heating, safety, and versatility are just some of their convenient features/benefits: Transparent sample vessels let you easily observe sample reactions; stainless steel sleeves protect glassware and distillation tube.
- Includes 3 x 20 mL ball-tube assembly, ball-tube drive unit and 60 mL rotation drying flask
- Fast heating to 300℃ in 10 min
- Steady vacuum for difficult sample solvents
- Shorter evaporation vessel eliminates cross-contamination and improves reproducibility
- Transparent sample vessel for complete visibility of sample during entire process
- Stainless steel protective sleeve ensures safety
- Temperature regulation from 40℃ to 300℃, ±5℃
- Reaches -70℃ for freeze-drying and sublimation with accessory circulator
- For small-scale distillation from 10 mL to 60 mL
- Rotation speed up to 50 rpm for uniform evaporation
- User-programmable distillation profiles
其他说明
Micro distillation applications require vacuum pumps, controllers, and a recirculating chiller.
法律信息
Büchi is a registered trademark of Büchi Labortechnik AG
产品性质
AC/DC input | 110 V / 230 V AC |
manufacturer/tradename | Büchi 046601 |
宽度 × 高度 × 直径 | 25.6 in. (65.0 cm) × 11.8 in. (30.0 cm) × 11.8 in. (30.0 cm) |
