产品说明
一般描述
Timestrip® PLUS indicators record elapsed time at or above a specified threshold temperature in a simple and quick way. They are small, self-adhesive labels that can be attached to or integrated into a product or device.
Visit our Timestrip Web Portal to learn more
应用
Manual activation button on top. The "ON" window turns blue to confirm it is armed. Blue color appears in the viewing window if a breach of the threshold temperature has occurred. Cumulative duration of all breaches is shown by progress of blue dye along time markers.
包装
92451-10EA: 10 labels in sachet
92451-100EA: 100 labels in sachet
92451-500EA: 500 labels in sachet
组分
Non-toxic, polymeric assembly multilayer and aluminum-plastic laminate encapsulating colored liquid chemicals
产品规格
- Threshold temperature: 25℃/77°F
- Usage: calibrated to an isothermal temperature environment of +27℃
- Time accuracy: ±15% in time under isothermal conditions
法律信息
Timestrip is a registered trademark of Timestrip Limited
Timestrip Plus is a trademark of Timestrip Limited
基本信息
| NACRES | NA.21 |
产品性质
| 描述 | Irreversible, single use |
| 质量 | Quality Assurance: Produced under ISO9001:2008 |
| 保质期 | limited shelf life, expiry date on the label |
| 储存条件 | room temperature (at 20-80% humidity) |
| 参数 | 12 h run-out window (calibrated at +27 ℃) |
| 尺寸 | 40 mm × 19 mm |
