产品说明
一般描述
BIOshell™ IgG 1000Å C4 is a high-speed, high-performance liquid chromatography column based on a new wide-pore (1000Å) Fused-Core® particle design. The Fused-Core particle provides a thin porous shell of high-purity silica surrounding a solid silica core. This particle design exhibits very high column efficiency due to the shallow diffusion paths in the 0.5-micron thin porous shell and the small overall particle size of 2.7-microns. The densely bonded, extensively endcapped dimethylbutyl stationary phase of BIOshell IgG 1000Å C4 provides a stable, reversed-phase packing that can be used for separating high molecular weight compounds such as proteins.
应用
UHPLC Analysis of Trastuzumab on BIOshell™ IgG 1000 Å C4, 2.7 μm
UHPLC Analysis of IgG2 on BIOshell™ IgG 1000 Å C4, C18, and Diphenyl, 2.7 μm
法律信息
BIOshell is a trademark of sigma-aldrich Co. LLC
Fused-Core is a registered trademark of Advanced Materials Technology, Inc.
基本信息
| NACRES | SB.52 |
产品性质
| 质量水平 | 100 |
| 物料 | stainless steel hardware |
| agency | suitable for USP L26 |
| 描述 | Shell thickness (0.5 μm) Solid core (1.7 μm) |
| 产品线 | BIOshell™ |
| 特点 | endcapped |
| specific analyte(s) | IgG |
| manufacturer/tradename | BIOshell™ |
| 包装 | 1 ea of |
| 标记范围 | 0.6% carbon loading |
| 参数 | 600 bar pressure 90 ℃ max. temp. |
| technique(s) | HPLC: suitable LC/MS: suitable UHPLC-MS: suitable UHPLC: suitable |
| 长度 × 内径 | 2 cm × 4.6 mm |
| 基质 | spherical silica particle platform superficially porous particle |
| 基质活性基团 | C4 (butyl) phase |
| 粒径 | 2.7 μm |
| 孔径 | 1000 Å |
| 表面积 | 22 m2/g |
| 操作pH范围 | 2 - 9 |
| 分离技术 | reversed phase |
安全信息
| 储存分类代码 | 11 - Combustible Solids |
| WGK | nwg |
| 闪点(F) | Not applicable |
| 闪点(C) | Not applicable |
