一般描述
25 Aluminium sheets 20 x 20 cm
Precoated Kieselguhr or mixed Silica gel/Kieselguhr plates are only of small importance nowadays. Kieselguhr layers are used like cellulose layers for the TLC separation of polar and moderately polar substances. Polyamide, on the other hand , is used for the separation of flavonoids and other phenolic substances.
联系
Replaces: 5567-7; 5567
分析说明
Layer thickness: 170 - 220 µm
Deviation of layer thickness per plate: ≤ 30 µm
Chromatografic testings:
A) colour test
hRf-values
- bleu vif organol, colour test, lipophile:
20 - 30
- Ceres Black G, colour test, lipophile: 50 - 60
- ceres Violet brn, colour test, lipophile: 60 - 70
Typical value determined on a conditioned sheet
Eluent: toluene (45% rel. humidity)
B) PHB- Ester
- phb-methylester, phb-ester-test: 20 - 30
- phb-ethylester, phb-ester-test: 30 - 40
- phb-propylester, phb-ester-test: 40 - 50
Typical value determined on a sheet
Eluent: Pentane/ glacial acetic acid (88/12 v/v)
产品性质
| 物料 | aluminum support silica gel 60 matrix |
| 质量水平 | 100 |
| 特点 | binder Organic Polymer fluorescent indicator |
| 包装 | pkg of 25 sheets |
| technique(s) | thin layer chromatography (TLC): suitable |
| 层厚度 | 200 μm |
| 薄片长度 × 宽度 | 20 cm × 20 cm |
| 粒径 | 10-12 μm |
| 孔径 | 60 Å medium pore diameter |
| 储存温度 | 2-30℃ |
