产品说明
一般描述
25 Aluminium sheets 20 x 20 cm
Our classical silica TLC plates are based on a combination of our proven silica gel 60 and the addition of a unique polymeric binder resulting in a very adherent and hard surface that will not crack or blister and even allow writing with a pensil on the surface without risk to damage the layer.
联系
Replaces: 16487-1; 16487
分析说明
Specific surface area (according to BET; 5-Pt. measurement): 480 - 540 m²/g
Pore volume (N₂-isotherm): 0.74 - 0.84 ml/g
d 50 (laser diffraction, size distribution): 9.5 - 11.5 µm
Layer thickness: 140 - 160 µm
Deviation of layer thickness per plate: ≤ 20 µm
Chromatographic testing:
colour test
hRf-values
- Benzene-azo-a-naphthylamine:
40 - 55
- Brillant red B: 60 - 75
- Erio green B: 75 - 90
separation number (colourtest, lipophile): ≥ 9.0
Typical value determined on a sheet
Eluent: Ethylmethylketone/ 1-propanol/ glacial acetic acid/ water (40/40/5/20 v/v/v/v)
产品性质
| 物料 | aluminum support silica gel 60 matrix |
| 质量水平 | 100 |
| 特点 | binder Organic Polymer fluorescent indicator: no |
| 包装 | pkg of 25 sheets |
| technique(s) | thin layer chromatography (TLC): suitable |
| 层厚度 | 200 μm |
| 薄片长度 × 宽度 | 20 cm × 20 cm |
| 粒径 | 10-12 μm |
| 孔径 | 60 Å medium pore diameter |
| 储存温度 | 2-30℃ |
