产品说明
一般描述
12 Glass plates 20 x 20 cm
These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples. Our concentrating zone plates are based on different adsorption properties of two adsorbents. The first is a large pore concentrating adsorbent where the samples are applied; the second is a selective layer for separation. Regardless of the spots’ shape, size, or position, the sample always concentrates as a narrow band where the two adsorbents overlap and where the separation starts. These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples.
联系
Replaces: 13793-7; 13793
分析说明
Layer thickness: 1700 - 2100 µm
Deviation of layer thickness per plate: ≤ 300 µm
layer thickness concentrating zone: 700 - 1100 µm
Fluctuation in the thickness of the concentration zone: ≤ 200 µm
Chromatographic testing:
colour test
hRf-values
- bleu vif organol, colour test, lipophile:
20 - 30
- Ceres Black G, colour test, lipophile: 45 - 55
- ceres Violet brn, colour test, lipophile: 60 - 75
Typical value determined on a conditioned plate
Eluent: toluene (45% rel. humidity)
产品性质
物料 | glass support silica gel 60 matrix |
质量水平 | 100 |
特点 | binder Organic Polymer fluorescent indicator |
包装 | pkg of 12 plates |
technique(s) | thin layer chromatography (TLC): suitable |
层厚度 | 2 mm |
板长度 × 宽度 | 20 cm × 20 cm |
粒径 | 20-40 μm |
孔径 | 60 Å medium pore diameter |
储存温度 | 2-30℃ |
