产品介绍：
产品说明
一般描述
These filter holders are ideal for ultracleaning or sterilizing batch volumes of liquids. The cylindrical barrel holds 100 mL (or 340 mL) of liquid, which is filtered by externally applied gas pressure through a suitable filter supported on the holder base.
Features & Benefits:
•Filter holder has reservoir to hold 100 mL (or 340 mL) of liquid for batch filtration
•Autoclavable with membrane in place for sterile filtration
Applications:
Batch Filtration
原理
压力
基本信息
| eCl@ss | 32031613 |
| NACRES | NB.24 |
产品性质
| 质量水平 | 100 |
| 物料 | PTFE seal anodized aluminum lock ring fluoroelastomer A seal silicone stopper stainless steel adapter (for tubing) stainless steel barrels stainless steel base stainless steel cap (for top) stainless steel support screen(s) (for filter) |
| 参数 | 6.9 bar max. inlet pressure (100 psi) |
| 高度 | 53.3 cm |
| 直径 | 7 cm |
| 过滤器直径 | 47 mm |
| 过滤面积 | 11.3 cm2 |
| prefilter diam. | 42 mm , thick depth prefilter 47 mm , membrane prefilter |
| 配件 | 9.5 mm ( 9.5 mm ( No. 8 outlet stopper for standard 1 L filtering flask (perforated silicone) |
| application(s) | filtration |
| 相容性 | for use with Stainless Steel Pressure Filter Holder |
| 运输 | ambient |
