产品说明
一般描述
The Hydrosol filter holder is designed for the filtration of flammable liquids. Unlike other filter holders, the Hydrosol filter holder includes a grounding unit to prevent sparking from static discharge, which can be a safety hazard.
Applications:
Vacuum Filtration of Flammable Liquids
XX2004720 Hydrosol Filter Holder, 47 mm, stainless steel
Replacement Parts
XX2004704 Funnel and Locking Ring Assembly, stainless steel
XX2004708 Support Screen, 47 mm, stainless steel
XX2004702 Base with Screen, gasket and support
XX2004703 Gasket, PTFE
XX2004718 No. 8 Stopper, 9.5 mm (3/8 in.) hole, silicone
XX20047RK Replacement Parts Kit for Hydrosol Filter Holder
Accessories
XX1004705 Vacuum Filtering Flask, 1 L
XX1004744 Vacuum Filtering Flask, 4L
XX7100004 Tubing 3/16 in. I.D. x 140 cm, silicone
XX6200006P Filter Forceps, blunt end, stainless steel
XX2604735 3-place Manifold, 47 mm, PVC
XX2504735 3-place Manifold, 47 mm, stainless steel
XX2504700 6-place Manifold, 47 mm, stainless steel
WP6211560 High Output Pump, 115 V/60 Hz
WP6222050 High Output Pump, 220 V/50 Hz
WP6210060 High Output Pump, 100 V/50-60 Hz
原理
真空
基本信息
| eCl@ss | 32031613 |
| NACRES | NB.24 |
产品性质
| 质量水平 | 100 |
| 物料 | Nylon wheel (lock) PTFE seal anodized aluminum lock ring silicone stopper stainless steel base stainless steel funnel(s) stainless steel support screen(s) (for filter) |
| 高度 | 22.9 cm |
| 直径 | 11.4 cm |
| 过滤器直径 | 47 mm |
| 过滤面积 | 9.6 cm2 |
| 漏斗容量 | 650 mL |
| prefilter diam. | 35 mm , thick depth prefilter 47 mm , membrane prefilter |
| 配件 | inlet funnel No. 8 outlet stopper for standard 1 L filtering flask (perforated silicone) |
| application(s) | filtration |
| 相容性 | for use with Hydrosol Filter holder |
| 运输 | ambient |
