产品介绍：
产品说明
一般描述
The Stainless steel filter holders are designed to ultraclean or sterilize liquids or gases by pressure filtration. PTFE-faced support screens permit autoclaving with membranes in place.
YY3009000 Filter Holder, 90 mm, stainless steel
Replacement Parts
XX2504705 Hose Adapter, 1/4 in. NPTM to 3/8 in. I.D.
XX4204708 Vent/Relief Valve
YY3009053 O-rings, 90 mm filter housing, PTFE
YY3009054 Support Screen, PTFE-coated
YY2209058 Underdrain Support, 90 mm
YY2209059 Support Legs
原理
压力
基本信息
| eCl@ss | 32031613 |
| NACRES | NB.24 |
产品性质
| 质量水平 | 100 |
| 物料 | 316 stainless steel PTFE seal anodized aluminum leg(s) |
| 参数 | 19 bar max. inlet pressure (275 psi) 5 bar max. differential pressure (75 psid) |
| 高度 | 17.1 cm , plus inlet connector |
| 直径 | 12.1 cm |
| 过滤器直径 | 90 mm |
| 过滤面积 | 45.5 cm2 |
| prefilter diam. | 75 mm |
| 重量 | 2.8 kg (6.2 lb) |
| 配件 | connector for 9.5 mm I.D. hose |
| application(s) | filtration |
| 相容性 | for use with Standing Stainless Steel Filter Holder |
| 运输 | ambient |
安全信息
| 储存分类代码 | 10-13 - German Storage Class 10 to 13 |
