PBDB-T-2Cl

Poly[[4,8-bis[5-(2-ethylhexyl)-4-chloro-2-thienyl]benzo[1,2-b:4,5-b′]dithiophene-2,6-diyl]-2,5-thiophenediyl[5,7-bis(2-ethylhexyl)-4,8-dioxo-4H,8H-benzo[1,2-c:4,5-c′]dithiophene-1,3-diyl]-2,5-thiophenediyl]

品牌
Sigma-Aldrich
CAS
2239295-71-5
货号
906352
包装型号
规格纯度
参考价格
6180.91 *本价格含增值税费
促销
数量
-+
产品介绍:

产品说明

应用

High-Efficiency Organic Solar Cells (OPVs)
Polymeric donor material
LUMO=−3.57 eV
HOMO=−5.32 eV

OPV Device Performance :
PBDB-T-2Cl:IT-4F
Voc= 0.86V
Jsc= 21.46 mA/cm2
FF= 0.75
PCE=13.9%

PBDB-T-2Cl (or PM7) is a wide bandgap polymer donor (n-type semiconductor) containing chlorinated thienyl benzodithiophene (BDT-2Cl) used in high performance polymer solar cells (PSCs). PBDB-T-2Cl-based devices exhibit higher open circuit voltage (Voc) than the PBDB-T-2F-based devices, due to lower molecular energy levels of PBDB-T-2Cl, and leading to an outstanding power conversion efficiency of over 14%.
In general, chlorination is more effective than fluorination in downshifting the molecular energy levels and broadening the absorption spectra.

基本信息

线性分子式(C68H76C12O2S8)n

产品性质

描述Band gap: 1.95 eV
Solubility:Soluble in 1,2-Dichlorobenzene
形式particles
分子量 50,000-100,000 g/mol by GPC
颜色 Fine
溶解性chlorobenzene: soluble
chloroform: soluble
轨道能量HOMO -5.52 eV
LUMO -3.57 eV
PDI2‑4

安全信息

储存分类代码11 - Combustible Solids
WGKWGK 3
闪点(F)Not applicable
闪点(C)Not applicable
