产品介绍：
产品说明
一般描述
Merocyanine dye, HB194 belongs to the class of absorption materials that are majorly used as donor molecules in organic electronic devices. It has a high absorption coefficient and good polarizing properties, which allow it to be utilized as a photorefractive material.
应用
VAC-processed single high-efficiency Small-BHJ solar cell based on the MC dye
OPV Device Structure: ITO/MoO3/HB194: C60/BPhen/Al
- JSC = 13.0 mA/cm2
- VOC = 0.96 V
- FF = 0.49
- PCE = 6.1%
包装
250 mg in poly bottle
基本信息
| 经验(实验)分子式 | C27H21N3O |
| 分子量 | 403.48 |
| MDL编号 | MFCD28009149 |
| PubChem化学物质编号 | 329765817 |
| NACRES | NA.23 |
产品性质
| mp | 288-290 ℃ |
| 质量水平 | 100 |
| λmax | ~578 nm in dichloromethane |
| SMILES string | O=C(C1=C2C=CC=C1)/C(C2=C(C#N)C#N)=C\C=C3C(C)(C)C4=C5C(CCCN5/3)=CC=C4 |
| InChI | 1S/C27H21N3O/c1-27(2)22-11-5-7-17-8-6-14-30(25(17)22)23(27)13-12-21-24(18(15-28)16-29)19-9-3-4-10-20(19)26(21)31/h3-5,7,9-13H,6,8,14H2,1-2H3/b21-12-,23-13+ |
| InChI key | XCFYTQCAMLKFSO-ABLMNQNHSA-N |
安全信息
| 象形图 |  |
| 警示用语： | Warning |
| 危险声明 | H315 - H319 - H335 |
| 预防措施声明 | P261 - P264 - P271 - P280 - P302 + P352 - P305 + P351 + P338 |
| 危险分类 | Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3 |
| 靶器官 | Respiratory system |
| 储存分类代码 | 11 - Combustible Solids |
| WGK | WGK 3 |
| 闪点(F) | Not applicable |
| 闪点(C) | Not applicable |
