产品说明
一般描述
2-{[7-(5-N,N-Ditolylaminothiophen-2-yl)-2,1,3-benzothiadiazol-4-yl]methylene}malononitrile (DTDCTB) is a conducting polymer that can be used as a donor molecule. It is majorly used in the development of organic electronics.
Device structure:
MoO3 (30nm) / DTDCTB (7nm) / DTDCTB:C60/C70 (40nm) / C60/C70 (7nm) / BCP (10nm) / Ag
Device performance:
- JSC = 14.68 mA/cm2
- VOC = 0.8 V
- FF = 0.5
- PCE = 5.81%
应用
DTDCTB is a π-conjugating polymer that can be used in the fabrication of organic solar cells (OSCs) and organic photovoltaic cells (OPVs).
A vacuum-deposited organic solar cell employing this novel donor-acceptor-acceptor (D-A-A) donor molecule; DTDCTB; combined with the electron acceptor C60/ C70 achieved a record-high power conversion efficiency (PCE) of 5.81%.
包装
250 mg in glass insert
基本信息
| 经验(实验)分子式 | C28H19N5S2 |
| 分子量 | 489.61 |
| MDL编号 | MFCD25976535 |
| PubChem化学物质编号 | 329767897 |
| NACRES | NA.23 |
产品性质
| 测定 | 99% (HPLC) |
| 形式 | powder |
| mp | 230-235 ℃ |
| 转变温度 | Tm 233 ℃ |
| λmax | 662-664 nm in dichloromethane |
| SMILES string | CC(C=C1)=CC=C1N(C2=CC=C(C)C=C2)C3=CC=C(C4=CC=C(C=C(C#N)C#N)C5=NSN=C54)S3 |
| InChI | 1S/C28H19N5S2/c1-18-3-8-22(9-4-18)33(23-10-5-19(2)6-11-23)26-14-13-25(34-26)24-12-7-21(15-20(16-29)17-30)27-28(24)32-35-31-27/h3-15H,1-2H3 |
| InChI key | BCJCBXQJAANTJL-UHFFFAOYSA-N |
安全信息
| 象形图 |  |
| 警示用语： | Warning |
| 危险声明 | H315 - H319 - H335 |
| 预防措施声明 | P261 - P264 - P271 - P280 - P302 + P352 - P305 + P351 + P338 |
| 危险分类 | Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3 |
| 靶器官 | Respiratory system |
| 储存分类代码 | 11 - Combustible Solids |
| WGK | WGK 3 |
| 闪点(F) | Not applicable |
| 闪点(C) | Not applicable |
