产品说明
一般描述
- Sterivex filter units work with syringes, peristaltic pumps or pressure vessels. They eliminate the risk of contamination associated with decanting or pipetting.
- Sterivex units are designed to dispense into virtually any storage container. The devices are available with different outlet connections (see table).
- Sterivex filter units can process volumes up to 1,000 mL or 2,000 mL, depending on the type of membrane used in the device. A choice of three different membranes is provided.
- Filter-sterilize volumes up to 1,000 mL or 2,000 mL, using Sterivex™ pressure-driven filter units (capacity depends on the type of membrane used in the device). With three different membrane options and a variety of outlet connection options, Sterivex
Features & Benefits:
- Works with a variety of pressure devices including syringes, perstaltic pumps and pressure vessels
- Comes in multiple membrane types to suit your application needs with capacities up to 2 L
Applications:
Sterilization of Aqueous Solutions
原理
压力
外形
Color Code: 透明
制备说明
Sterilization Method
γ 射线照射
其他说明
Directions for Use
- Organism Retention: Microorganisms
- Mode of Action: Filtering
- Application: Sterile Filtration
- Intended Use: Large-volume filtration using positive pressure
- Instructions for Use: Please refer to Instructions for Use section of Sterivex™ user guide
- Storage Statement: Store in dry location
- Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
法律信息
Durapore is a registered trademark of Merck KGaA, Darmstadt, Germany
Eastar is a trademark of Eastman Chemical Company
Luer-Lok is a registered trademark of Becton-Dickinson & Co.
Sterivex is a trademark of Merck KGaA, Darmstadt, Germany
基本信息
eCl@ss | 32031690 |
NACRES | NB.22 |
产品性质
物料 | Eastar™ PVDF membrane |
质量水平 | 400 |
无菌性 | sterile |
特点 | holdup volume 2.2 mL hydrophilic |
manufacturer/tradename | Sterivex™ |
参数 | 1000 mL process volume 3.1 bar max. inlet pressure (45 psi) 45 ℃ max. temp. |
technique(s) | sterile filtration: suitable |
高度 | 85 mm |
直径 | 5.4 cm |
过滤面积 | 10 cm2 |
基质 | Durapore® |
孔径 | 0.45 μm nominal pore size 0.45 μm pore size |
试验参数 | sample volume: 1 L |
配件 | female Luer-Lok® inlet fitting (with upstream vent) outlet filling bell |
运输 | ambient |
