产品说明
一般描述
Sheet Resistivity is 3.6 - 4 mΩ / square / mil. (at a 180℃ cure temperature)
应用
Use this Conductive Silver Ink to achieve outstanding conductivity at low cure temperatures when printing on a variety of substrates, including glass and polyesters (PET/PEN) and ITO/FTO coated substrates.
This Conductive Silver Printing Ink provides outstanding conductivity at low cure temperatures. It provides extremely low resistance of printed conducting tracks, essential for the photovoltaic applications, and is a key enabler in plastic electronics such as DSSC; OPV; CdTe solar cells etc.,by providing lowest track resistances of printed current collectors.
The Conductive Silver Printing Ink is comprised of a mixture of pure silver particles and an organometallic silver compound in an organic medium. When printed on polyester films, and then heated to 160 - 180℃, the particles consolidate to form a chemically-welded, continuous metal track.
包装
10, 20 g in glass bottle
法律信息
Product of Dyesol®
Dyesol is a registered trademark of Greatcell Solar
基本信息
| NACRES | NA.23 |
产品性质
| 测定 | 75-85% (Solids content) |
| 质量水平 | 100 |
| 形式 | paste (white) |
| 体积电阻率 | 9-10 μΩ-cm |
| 粘度 | 9000-12000 mPa.s (at shear rate of 10 sec-1 at 25℃) |
安全信息
| 象形图 |  |
| 警示用语： | Warning |
| 危险声明 | H315 - H319 |
| 预防措施声明 | P305 + P351 + P338 |
| 危险分类 | Eye Irrit. 2 - Skin Irrit. 2 |
| 储存分类代码 | 10 - Combustible liquids |
| WGK | WGK 3 |
| 闪点(F) | 174.2 °F |
| 闪点(C) | 79 ℃ |
