产品介绍：
产品说明
一般描述
Filter Type: 超滤
Device Configuration: 取样皿滤膜
特点和优势
Type C screen (coarse screen)
其他说明
These products are manufactured in a facility which adheres to Good Manufacturing Practices.
分析说明
Total Organic Carbon (TOC) Residue: meets TOC <= 5 ppm in retentate effluent, after a WFI flush of 20 L/m2
法律信息
Pellicon is a registered trademark of Merck KGaA, Darmstadt, Germany
ULTRACEL is a registered trademark of Merck KGaA, Darmstadt, Germany
产品性质
| 质量水平 | 400 |
| 物料 | EPDM rubber seal PPO/PS blend cap (for Housing/Core/Port) TPE seal composite regenerated cellulose (CRC) epoxy potting (BPA-free) polyester screen polypropylene screen polyurethane potting |
| 无菌性 | sterile; γ-irradiated |
| 特点 | holdup volume 26 mL (in feed channel) holdup volume 62 mL (in permeate channel) |
| manufacturer/tradename | Pellicon® |
| 参数 | 4-8 L/min-m2 flow rate (feed) 50 psi max. transmembrane pressure (3.5 bar) at 4-30 ℃ (forward) 80 psi max. inlet pressure (5.5 bar) at 4-30 ℃ |
| technique(s) | analytical sample preparation: suitable protein purification: suitable |
| 长度 | 13.9 in. (35.3 cm) |
| 宽度 | 1.5 in. (3.8 cm) |
| membrane nominal area | 0.1 m2 |
| 尺寸 | 0.1 m2 |
| 基质 | Ultracel® |
| 孔径 | 30 kDa NMWCO |
| pH值(酸碱度) | 2-13 |
| 配件 | |
| 储存温度 | 2-8℃ |
