产品介绍：
产品说明
一般描述
Device Configuration: Cartridge
产品规格
Filter Grade: AP15
制备说明
Sterilization Method
10 autoclave cycles or SIP @ 126 °C for 30 min
Sanitization Protocol
30 min with hot water @ 80 °C
分析说明
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥5 L
Gravimetric Extractables: after 24-h soak in water
其他说明
Directions for Use
- Organism Retention: Microorganism reduction
- Mode of Action: Filtration (nominal)
- Application: BioProcessing
- Intended Use: Efficient particle and microorganism reduction
- Instructions for Use: Please refer to the Polygard® and CLARIGARD® Cartridges user guide
- Storage Statement: Store in dry location
- Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
法律信息
CLARIGARD is a registered trademark of Merck KGaA, Darmstadt, Germany
POLYGARD is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031690 |
产品性质
| 物料 | EPR seal polypropylene polypropylene support |
| 质量水平 | 400 |
| 特点 | hydrophilic |
| manufacturer/tradename | Polygard |
| 参数 | 4.8 bar max. differential pressure (70 psid) at 25 ℃ 4.8 bar max. inlet pressure (70 psi) at 25 ℃ |
| cartridge nominal length | 10 in. (25 cm) |
| 直径 | 7.0 cm (2.75 in.) |
| 过滤面积 | 0.42 m2 |
| 杂质 | ≤0.5 EU/mL bacterial endotoxins (LAL test, Aqueous extraction) |
| gravimetric extractables | ≤50 mg |
| 孔径 | 30.0 μm nominal pore size 30.0 μm pore size |
| input | sample type liquid |
| cartridge code | Code 7 (2-226; O-rings w/locking-tabs) |
