产品介绍：
产品说明
一般描述
Device Configuration: 取样皿滤膜
特点和优势
Format: Single Layer
其他说明
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Directions for Use:
- Organism Retention: Bacterial
- Mode of Action: Filtration (size exclusion)
- Appliication: Protein Purification
- Intended Use: Reduction or removal of microorganism/bioburden
- Instructions for Use: Please refer to the installation and wetting sections of OptiScale® 47 Capsulle Filter with Polygard® CN Media user guide
- Storage Statement: Store in original packaging at room temperature
- Disposal Statement: Dispose of in accordance with applicable federal, state, and local regulations
制备说明
Sterilization Method
3 autoclave cycles of 60 min @ 126 °C; not in-line steam sterilizable
分析说明
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
法律信息
OPTISCALE is a registered trademark of Merck KGaA, Darmstadt, Germany
POLYGARD is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031610 |
产品性质
| 质量水平 | 400 |
| 物料 | PVDF vent cap fluoroelastomer FKM seal polycarbonate polypropylene polypropylene support |
| reg. compliance | meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials) |
| manufacturer/tradename | OptiScale® |
| 参数 | 25 ℃ max. inlet temp. 5.5 bar max. inlet pressure (80 psi) at 25 ℃ 80 psig max. inlet pressure |
| 直径 | 6.9 cm (2.7 in.) |
| 过滤面积 | 17.7 cm2 |
| inlet connection diam. | 1/4 in. |
| outlet connection diam. | 1/4 in. |
| 杂质 | ≤0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction) |
| 基质 | Polygard®-CN |
| 孔径 | 1.2 μm nominal pore size 1.2 μm pore size |
| input | sample type liquid |
| 配件 | inlet hose barb 6 mm ( outlet hose barb |
