产品介绍：
产品说明
一般描述
Device Configuration: 取样皿滤膜
其他说明
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Directions for Use
- Organism Retention: Microorganism
- Mode of Action: Filtration (size exclusion)
- Application: BioProcessing
- Intended Use: Reduction or removal of microorganism/bioburden
- Instructions for Use: Please refer installation and wetting sections of OPTISCALE®-25 user guide
- Storage Statement: Please refer to OPTISCALE®-25 user guide
- Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
制备说明
Sterilization Method
3 autoclave cycles of 60 min @ 126 °C
分析说明
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
法律信息
MILLIPORE EXPRESS is a registered trademark of Merck KGaA, Darmstadt, Germany
OPTISCALE is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031690 |
产品性质
| 质量水平 | 400 |
| 物料 | PVDF vent cap fluoroelastomer FKM seal polycarbonate polyethersulfone polypropylene support |
| reg. compliance | meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials) |
| 特点 | hydrophilic |
| manufacturer/tradename | Millipore Express® |
| 参数 | 25 ℃ max. inlet temp. 5.5 bar max. inlet pressure (80 psi) at 25 ℃ 80 psig max. inlet pressure |
| 长度 | 9.4 cm (3.70 in.) |
| cartridge nominal length | 3.70 in. (94 mm) |
| 直径 | 6.9 cm (2.7 in.) |
| 过滤面积 | 17.7 cm2 |
| inlet connection diam. | 1/4 in. |
| outlet connection diam. | 1/4 in. |
| 基质 | Millipore Express® SHF |
| 孔径 | 0.2 μm nominal pore size 0.2 μm pore size |
| bubble point | ≥4000 mbar (58 psig), air with water at 23 ℃ |
| 配件 | inlet hose barb 6 mm ( outlet hose barb |
