产品说明
一般描述
Millipak® 膜产品设计用于实验室的常规过滤应用。经证明，Millipak® 过滤器是同类产品中的佼佼者，用于净水系统，提供不含颗粒物和细菌的水，满足科研应用的严格要求。
应用
提供不含细菌和颗粒物的水，适合实验室中细菌控制至关重要的技术(如细胞培养、微生物培养基制备等)。
特点和优势
- Millipak® 膜过滤器由 Durapore® PVDF 膜制成，具有高流速和高通量、溶出物少、化学相容性广的特点。
- 伽马射线辐照可进一步控制细菌。
- 膜由带有通道的硬质塑料盘支撑，该通道可确保高水流量和耐压力变化性能，而不会引起膜破裂的风险
- Millipak®膜过滤器采用独特的、简洁的堆叠盘式设计，可最大程度减少滞留体积和颗粒脱落。
- 连接到分配水点的出口，如Milli-Q® 净水系统的POD。保护罩可防止水分配过程中空气中细菌污染物的侵入。
- 保护罩可防止分配过程中空气中细菌的侵入。
- 轻松的维护：该过滤器可轻松过滤和更换。
- 设备配置：伽玛金胶囊
- 无菌单位。
- 密封交付，并附有质量证明书
其他说明
这些产品是在符合 FDA 良好生产规范的工厂内生产的。
Directions for Use
- Organism Retention: Microorganisms
- Mode of Action: Filtering
- Application: General laboratory analysis
- Intended Use: Water purification
- Instructions for Use: This item provides water filtered through 0.22 μm sterilizing-grade membranes and is a device that meets requirements under FIFRA. Refer to system equipment user guide section "Using the System" (available on USB key in the system box).
- Storage Statement: Store in dry location
- Disposal Statement: Dispose of in accordance with applicable federal, state and local regulations.
制备说明
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
分析说明
细菌保留
使用 ASTM® F838 方法，对样品进行最小保留的缺陷短波单孢菌挑战浓度为 1 x 10⁷ CFU/cm² 的定量保留。
重量萃取物：200 mL 冲洗后在室温下于水中 24 小时使用灭菌装置
法律信息
ASTM is a registered trademark of American Society for Testing and Materials
Durapore is a registered trademark of Merck KGaA, Darmstadt, Germany
Emprove is a registered trademark of Merck KGaA, Darmstadt, Germany
MILLI-DI is a registered trademark of Merck KGaA, Darmstadt, Germany
MILLIPAK is a registered trademark of Merck KGaA, Darmstadt, Germany
Milli-Q is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 33050190 |
| NACRES | JA.14 |
产品性质
| 物料 | PVDF membrane |
| 质量水平 | 400 |
| 无菌性 | sterile |
| 产品线 | EMPROVE® Filter |
| 特点 | hydrophilic |
| 包装 | pkg of 2 units |
| manufacturer/tradename | Millipak® |
| 参数 | 0.35 bar max. differential pressure at 123 ℃ (Forward) 0.7 bar max. differential pressure at 25 ℃ (Reverse) 1.7 bar max. differential pressure at 80 ℃ (Forward) 4.1 bar max. differential pressure at 25 ℃ (Forward) 5.2 bar max. inlet pressure at 25 ℃ |
| inlet connection diam. | 1/4 in. |
| outlet connection diam. | 1/4 in. |
| 杂质 | <0.5 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction) |
| gravimetric extractables | ≤1.5 mg/device |
| 基质 | Durapore® |
| 孔径 | 0.22 μm pore size |
| 配件 | male NPT inlet connection outlet stepped hose barb (with bell) |
| 相容性 | for use with Alpha-Q for use with Milli-DI® for use with Milli-Q® Academic for use with Milli-Q® Biocel for use with Milli-Q® Direct for use with Milli-Q® Element for use with Milli-Q® Gradient for use with Milli-Q® Plus for use with Milli-Q® Reference for use with Milli-Q® Synthesis |
| 运输 | ambient |
