产品说明
一般描述
Glass plunger valve has a 5 mm I.D. thermowell for a thermocouple wire or sheathed probe up to 1/8 in. (3.2 mm) diam. Overall length of plunger valve is 190 mm. The thermowell length is 70 mm. Plunger has a hole on the side that, when positioned in relation to the O-ring seal, allows tube to be open or closed to the atmosphere (i.e. pull to close, push to open).
Complete item consists of tube with #15 Ace-Thred, PTFE bushing with FETFE® O-ring, and plunger valve with thermowell.
Replacement FETFE O-rings:
Ace-Thred #Front SealBack Seal
7 Z504661 Z504742
15 Z504858 Z505021
25 Z505056 Z505110
CAUTION: This glassware is not guaranteed against breakage caused by pressure or vacuum. These tubes should never be used if scratched or otherwise damaged.
法律信息
FETFE is a registered trademark of Ace Glass, Inc.
基本信息
| NACRES | NB.11 |
产品性质
| 物料 | PTFE cap borosilicate glass tube cap (Front-Seal Plunger Valve) clear tube glass round bottom screw top cap (plugseal) white cap |
| 无菌性 | non-sterile |
| 特点 | graduations: no internal thread |
| 包装 | pack of 1 ea |
| manufacturer/tradename | Ace Glass 8648-170 |
| 长度 × 外径 | 20.3 cm × 38.1 mm |
| 容量 | ~120 mL |
| 直径 | 38.1 mm |
| binding type | non-treated surface |
