一般描述
IKA® MF 10.2 Impact Grinding Head
For crushing brittle, hard materials such as minerals, building materials up to Mohs hardness 6. Before being discharged, the ground material passes through a sieve. This sieve is interchangeable and available in different hole sizes (not incl. with delivery). The ground material can then be collected using an NS 29 standard ground vessel.
- Process type: inline
- Circumferential speed max.: 31.4 m/s
- Feed hardnessmax.: 6 Mohs
- Feed grain size max.: 10 mm
- Material milling chamber: stainless steel 1.4308
- Milling chamber, can be cooled with water: no
- Mill feed can be cooled in milling chamber with dry ice: yes
- Mill feed can be cooled in milling chamber with liquid nitrogen: no
- Dimensions (W x H x D): 320 x 450 x 300 mm
- Weight: 2.7 kg
法律信息
IKA is a registered trademark of IKA-Werke GmbH & Co. KG
基本信息
NACRES | NB.74 |
产品性质
物料 | stainless steel (milling chamber) |
包装 | case of 1 pack of 1 |
manufacturer/tradename | IKA 2871000 |
宽度 × 高度 × 直径 | 320 mm × 450 mm × 300 mm |
重量 | 2.7 kg |
适用性 | suitable for (crushing brittle, hard materials such as minerals, building materials up to Mohs hardness 6) |
