Straight channel chip (4 parallel channels)

产品说明

应用

Straight channel chip (4 parallel channels), Fluidic 145, PMMA is the same dimensions of a microscope slide (75.5 mm x 25.5 mm x 1.5 mm). The channel distance from center to center is 4.5 mm according to the spacing of a 384-microtiter plate. The fluidic chips are available with Mini Luer interfaces that can be used with the respective counterpart. Alternatively, standard Luer interfaces are convenient. Channels can be orientated crosswise or lengthwise on the chip.
Chip Properties:

• 4 parallel channels
• Mini Luer Interface
• Material: Poly(methyl methacrylate) (PMMA)
• Slide Dimensions: 75.5 mm x 25.5 mm x 1.5 mm
• Channel to channel distance: 4.5mm
• Channel Dimensions: 50μm (width) x 50μm (depth) x 58.5mm (length)
