产品说明
一般描述
We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.
Lithium titanate (LTO) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage.
应用
Lithium titanate (LTO) spinel electrode sheet can be used as an anode material, which shows an ion conductivity of 10−3 Scm−1 at room temperature. It can also be used as an alternative to conventional graphite materials. It can further be used in the fabrication of high-performance lithium-ion batteries for electric vehicles (EVs).
包装
1 ea in glass bottle
其他说明
Crystal Structure: Spinel, cubic, Fd-3m
Operating Condiditons:
- Recommended maximum charge voltage: 3.0 V vs Li/Li+
- Recommended maximum charge current: 5 C
- Recommended cut-off voltage for discharge: 1.0 V vs Li/Li+
- Recommended maximum discharge current: 10 C
基本信息
| 线性分子式 | Li4Ti5O12 |
| MDL编号 | MFCD11656084 |
| PubChem化学物质编号 | 329767159 |
| NACRES | NA.23 |
产品性质
| 质量水平 | 100 |
| 测定 | ≥98% |
| 环保替代产品特性 | Design for Energy Efficiency Learn more about the Principles of Green Chemistry. |
| 标记范围 | ≥80% loading |
| 标称电压 | 1.5 V, Li/Li+ |
| 尺寸 | 5 in. × 10 in. |
| 厚度 | 25-50 μm |
| 容量 | 150 mAh/g(minimum) 160 mAh/g(nominal at 0.1C) |
| mp | >1000 ℃ |
| application(s) | battery manufacturing |
| 环保替代产品分类 | Enabling |
| SMILES string | [Li+].[Li+].[Li+].[Li+].[O-][Ti](=O)O[Ti](O[Ti]([O-])=O)(O[Ti]([O-])=O)O[Ti]([O-])=O |
| InChI | 1S/4Li.12O.5Ti/q4*+1;;;;;;;;;4*-1;;;;; |
| InChI key | BNQVSKURWGZJMY-UHFFFAOYSA-N |
安全信息
| 储存分类代码 | 11 - Combustible Solids |
| WGK | WGK 3 |
