产品说明
一般描述
Device Configuration: Process Scale Pod
应用
Primary clarification directly out of the bioreactor
产品规格
Trace metals were measured post pure water flush of 50 L/m2 of surface area and 24-hour static soak in pure water. Values based on average of metals extractibles data from three separate uPod
Filter Grade: C0SP
制备说明
Sterilization Method
Integrity is maintained after 1 autoclave cycle of 60 min @ 123 ºC. Filtration performance may be impacted post autoclave. Recommended for post use decontamination only.
分析说明
Product Water Conductivity at 25℃: after a pure water flush 50 L/m2 (5 liter per ft2) of media surface area (300 LMH, 10 min). At the end of the flush, a sample was pulled for conductivity measurement. Devices were not autoclaved.
法律信息
Emprove is a registered trademark of Merck KGaA, Darmstadt, Germany
MILLISTAK+ is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031690 |
产品性质
| 物料 | acrylic polypropylene silica filter aid |
| 质量水平 | 400 |
| 描述 | Primary clarification directly out of the bioreactor |
| 产品线 | EMPROVE® Filter |
| 特点 | hydrophilic |
| manufacturer/tradename | Millistak+® |
| 参数 | 30 psid max. differential pressure (2.1 bar) at 25 ℃ (Reverse) 30 psid max. differential pressure (2.1 bar) at 80 ℃ (Forward) 50 psid max. inlet pressure (3.5 bar) at 80 ℃ |
| 高度 | 12.5 in. (32 cm) |
| 长度 | 24.2 in. (62 cm) |
| depth | 3.2 in. (8.1 cm) |
| 过滤面积 | 0.33 m2 |
| 杂质 | <0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction) |
| input | sample type liquid |
| 电导率 | 18.9-41.5 μS/cm at 25 ℃ (product water) |
| filter grade | C0SP |
