产品说明
一般描述
Device Configuration: Single Layer Pod
应用
For clarification of serum, plasma, vaccines, cell culture or other fluids.
产品规格
Filter Grade: CE50
Per 24-hour static soak in 10 L pure water post autoclave (1 cycle of 30 minutes at 123 °C) and pure water flush of 10 L per ft2 (100 L/m2) of surface area.
Sodium: ≤9.91 mg/ft2
Calcium: ≤1.46 mg/ft2
Magnesium: ≤0.662 mg/ft2
Mercury: ≤0.0004 mg/ft2
Chromium: 0.0003 mg/ft2
Aluminum: ≤0.059 mg/ft2
Potassium: ≤0.042 mg/ft2
Lead: ≤0.0004 mg/ft2
Arsenic: ≤0.002 mg/ft2
Cobalt: 0.0002 mg/ft2
Iron: ≤0.042 mg/ft2
Manganese: ≤0.001 mg/ft2
Titanium: <0.001 mg/ft2
Zinc: ≤0.003 mg/ft2
Nickel: ≤0.0004 mg/ft2
Copper: ≤0.0004 mg/ft2
制备说明
Sterilization Method
1 autoclave cycle of 60 minutes at 123 °C
分析说明
Product Water Conductivity at 25℃: post autoclave (1 cycle of 60 minutes at 123 ℃) and pure water flush of 5 liters per ft2 (50 L/m2) of media surface area
法律信息
MILLISTAK+ is a registered trademark of Merck KGaA, Darmstadt, Germany
基本信息
| eCl@ss | 32031690 |
产品性质
| 质量水平 | 400 |
| 物料 | cellulose glass filled polypropylene |
| 描述 | For clarification of serum, plasma, vaccines, cell culture or other fluids. |
| 特点 | hydrophilic |
| manufacturer/tradename | Millistak+® |
| 参数 | 1.0 bar max. differential pressure (15 psid) at 80 ℃ (Forward) 1.0 bar max. inlet pressure (15 psid) at 80 ℃ 2.1 bar max. differential pressure (30 psid) at 25 ℃ (Forward) 2.1 bar max. differential pressure (30 psid) at 25 ℃ (Reverse) 3.5 bar max. inlet pressure (50 psid) at 25 ℃ |
| 高度 | 32 cm (12.5 in.) |
| 长度 | 62 cm (24.2 in.) |
| 过滤面积 | 0.77 m2 |
| 杂质 | <0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction) |
| input | sample type liquid |
| 电导率 | 1.52-1.94 μS/cm at 25 ℃ (product water) |
| filter grade | CE50 |
安全信息
| 储存分类代码 | 10-13 - German Storage Class 10 to 13 |
