Opticap® XL5 Polygard® CR

品牌
Millipore
货号
KR01A05HH1
规格纯度
inlet connection diam. 9/16 in., pore size 1.0 μm, cartridge nominal length 5 in. (12.5 cm)
参考价格
1567.31 *本价格含增值税费
促销
数量
-+
产品介绍:

产品说明

一般描述

Device Configuration: 取样皿滤膜

特点和优势

Format: Single Layer

包装

Double Easy-Open bag

其他说明

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.

制备说明

Sterilization Method
3 autoclave cycles of 30 min @ 126 °C; not in-line steam sterilizable

分析说明

Gravimetric Extractables: after 24 hours in water at controlled room temperature
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥2.5 L

法律信息

OPTICAP is a registered trademark of Merck KGaA, Darmstadt, Germany
POLYGARD is a registered trademark of Merck KGaA, Darmstadt, Germany

免责声明

EMD Millipore Corporation certifies that this product complies with the European Pressure Equipment Directive, 97/23/EC of 29 May 1997. This product has been classified under Article 3 § 3 of the Pressure Vessel Directive. It has been designed and manufactured in accordance with sound engineering practice to ensure safe use. In compliance with Article 3 § 3 of this Pressure Vessel Directive, this product does not bear the CE mark.

产品性质

质量水平400
物料polypropylene
polypropylene housing
polypropylene support
polypropylene vent cap
silicone seal
reg. compliancemeets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)
manufacturer/tradenameOpticap®
参数1.0 bar max. inlet pressure (15 psi) at 80 ℃
2.75 bar max. inlet pressure (40 psi) at 60 ℃
25 ℃ max. inlet temp.
4.8 bar max. differential pressure (70 psid) at 20 ℃
5.5 bar max. inlet pressure (80 psi) at 25 ℃
80 psig max. inlet pressure
长度21.6 cm (8.5 in.)
cartridge nominal length5 in. (12.5 cm)
直径10.7 cm (4.2 in.)
inlet connection diam.9/16 in.
inlet to outlet W21.6 cm (8.5 in.)
outlet connection diam.9/16 in.
总尺寸5 in.
杂质≤0.5 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)
<0.5 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction)
gravimetric extractables≤30 mg/capsule
基质Polygard®-CR
孔径1.0 μm nominal pore size
1.0 μm pore size
inputsample type liquid
配件 inlet hose barb
14 mm (9/16 in.) inlet/outlet hose barb
outlet hose barb
