| DC V | 6.000/60.00/600.0/1000V (自动量程)
±0.5%rdg ±3dgt (6/60/600V)
±0.8%rdg ±3dgt (1000V) |
|---|
| DC mV | 600.0mV
±1.5%rdg ±3dgt |
|---|
| 直流钳形传感器 | 60.00/200.0A (自动量程)
±1.5%rdg ±3dgt +传感器精确度 |
|---|
| AC V | 6.000/60.00/600.0/1000V (自动量程)
±1.0%rdg ±3dgt [40 - 500Hz] (6/60/600V)
±1.3%rdg ±3dgt [40 - 500Hz] (1000V) |
|---|
| AC mV | 600.0mV
±2.0%rdg ±3dgt [40 - 500Hz] |
|---|
| 交流钳形传感器 | 60.00/200.0A (自动量程)
±2.0%rdg ±3dgt +传感器精确度 [40 - 500Hz] |
|---|
| Ω | 600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (自动量程)
±0.5%rdg ±4dgt (600Ω)
±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ)
±1.5%rdg ±3dgt (40MΩ) |
|---|
| 导通蜂鸣 | 600Ω (低于90Ω蜂鸣器鸣叫) |
|---|
| 二极管测试 | 开环电压: < 3.0V |
|---|
| 电容测试 | 60.00/600.0nF/6.000/60.00/600.0/1000μF
±2.0%rdg ±5dgt (60/600nF)
±5.0%rdg ±5dgt (6/60/600/1000μF) |
|---|
| 频率 | 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt |
|---|
| DUTY | 10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz] |
|---|
| 安全规格 | IEC 61010-1 CAT IV 300V/ CAT III 600V/ CAT II 1000V
IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS) |
|---|
| 电池 | R03 (1.5V) × 2 |
|---|
| 外形尺寸 | 155(L) × 75(W) × 40(D)mm |
|---|
| 重量 | 250g Approx. (含电池) |
|---|
| 附件 | 翼型支架
7066A (测试线)
R03 × 2,使用说明书 |
|---|
| 可选件 | 7234 (鳄鱼夹测试线)
8161 (AC钳形传感器)
8115 (AC/DC钳形传感器)
9189 (磁性挂钩) |
|---|
